HCB 602H Adam Equipment Highland Balance


General

The Highland® offers advanced features in a compact, durable balance that stacks for easy storage. Suitable for many tasks, Highland provides fast, accurate weighing in a number of different environments – from science research in the laboratory or field, to manufacturing operations.

KEY FEATURES

• Vivid, backlit LCD easily visible in any lighting conditions
• Programmable backlight can be set to “always on,” “always off” or “light only when weighing”
• Capacity tracker built into display for easily monitoring possible overloads
• Balances stack efficiently and safely to save space (120mm pan size only)
• Colour-coded keys facilitate quick recognition of the most frequently used buttons
• Dual tare keys facilitate operation with either the left or right hand
• Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
• Security slot for optional Kensington-type lock and cable to help prevent theft
• Large, grade 304 stainless steel pan allows easy cleaning
• Solid ABS housing is durable for industrial uses
• Three-point ShockProtect® feature helps prevent overload damage to internal components
• Hook included for weighing below the balance
• Internal calibration eliminates need for external weight set
• USB and RS-232 interfaces provide speedy communication with computers and printers
• Audible overload alarm warns when capacity has been exceeded
 External calibration allows for verification and adjustment with weights
• Selectable digital filtering helps minimise effects of vibration and disturbances
• Parts counting with pre-set sample sizes
• Memory accumulation totals results
• Zero-tracking feature ensures display returns to zero reading
• AC adapter included
• Rechargeable battery included for operation almost anywhere
• Programmable auto power-off to save energy

Specifications

Capacity600g
Readability0.1g
Repeatability0.1g
Linearity (+/-)0.2g
Pan Size120mm ø
Weighing Unitsg, lb, oz, N, GN, ct, dr, dwt, mm, ozt, T, tl.H, tl.S, tl.T
Stabilisation Time (sec)2
InterfaceRS-232, USB
CalibrationExternal calibration / Internal manual calibration
DisplayBacklit LCD with 18mm-high digits
Power Supply12VDC 50/60Hz 800mA adapter / Internal rechargeable battery
Operating Temperature0° to 40°C
HousingABS plastic
Overall Dimensions174x252x80mm (wxdxh)
Net Weight2kg
Additional AccessoriesYes
